3KW BTMS System - TKT BCS 3R
The 3KW BTMS system is suitable for 6-7m electric buses as well as heavy machinery and equipment.
By maintaining ideal temperature levels, TKT’s system safeguards the health and performance of the battery, delivering consistent results in different environments. Additionally, our systems can be integrated with commercial electric vehicle architectures, which makes them ideal for automakers around the world.
– Cooling: 3-4KW
– Heating: 1-2KW
– Voltage: 240-350V DC
– Coolant Flow: 45-60 L/Minute
– Installation: Roof top/Under chassis
Recommended Products
TKT’s wide range of thermal management systems for lithium-ion batteries are suitable for electric buses, electric trucks, construction vehicles, municipal vehicles, ships and other commercial vehicles. High quality, high volume and wholesale pricing make us an obvious partner for you.
We provide design and technical support to the world’s leading vehicle manufacturers. These include BYD, Tata Motors, Switch Mobility and more than 150 other outstanding companies.
All Series Specification Table:
| Model | TKT-BCS3-R | TKT-BCS3-CW | TKT-BCS5-R | TKT-BCS5-CW | TKT-BCS10-CW |
|---|---|---|---|---|---|
| Cooling Capacity | 3KW | 3KW | 5KW | 5KW | 10KW |
| Heating Capacity | 3KW | 3KW | 5KW | 5KW | 6KW |
| Voltage | 240-360VDC | 240-360VDC | 450-750VDC | 450-750VDC | 450-750VDC |
| Coolant Flow | 45-60L/Minute | 45-60L/Minute | 45-60L/Minute | 45-60L/Minute | 45-60L/Minute |
| Weight | 25kg | 25kg | 40kg | 30kg | 40kg |
| Size(L*W*H) | 587*355*242mm | 750*355*242mm | 750*550*293mm | 618*350*392mm | 780*430*380mm |
| Installation | Roof Top | Chassis | Roof Top | Chassis | Roof Top |
Advantages of Our Electric Vehicle Thermal Management System
1. Our battery thermal management system comes with a patented design and trusted expertise, which helps to improve battery reliability.
2. We use liquid cooling combined with PTC heating to ensure long-lasting and stable performance of our product.
3. Our product is lighter in weight compared to other products in the market, which reduces the burden on the vehicle.
4. We have adopted an integrated layout program, which allows us to provide ATS and BTMS system integration solutions.
5. Our system uses CAN control to avoid any damage to the battery pack due to misoperation. It adapts to changing conditions and ensures high-precision control.
6. Our product comes with intelligent thermal control, which prevents overheating or overcooling. This effectively extends battery cycle life.
7. Our product has premium quality and performance, which is recognized by customers worldwide. We have a large number of cases for you to choose from, or you can choose our exclusive OEM service.
Battery thermal management system for electric vehicles are critical for optimizing performance, extending battery life, ensuring safety, optimizing charging cycles, adapting to different environments, and promoting environmental sustainability. While advances in battery technology have brought tremendous benefits, battery thermal management and battery cooling system remains a fundamental aspect that cannot be ignored. Using our BTMS not only enhances the user experience, but also protects against potential hazards and maximizes the overall potential of battery-powered devices.
TKT BTMS Introduction and Company Advantages
TKT started its research and design types of Battery Thermal Management Systems (BTMS) in 2012. The aim was to optimize battery performance, increase energy efficiency and extend battery life. To address these challenges, TKT has developed a 3KW-10KW Battery Thermal Management System for electric buses, electric trucks, and heavy transportation equipment. This system solves the problems by maintaining the temperature of the battery pack within the appropriate range through coolant cooling and PTC heating. This ensures a longer range and service life of the electric vehicle. TKT can offer more affordable factory prices and availability to OEM customers worldwide, giving them a competitive advantage.
TKT HVAC is a global leading BTMS manufacturer and supplier, with a team of 100+ talented engineers. The team includes design, structural, electrical, test, EMI/EMC, and after-sales engineers with complete design, development, testing and certification capabilities.
In addition to products, TKT also offers comprehensive services. Their technicians will advise you from the beginning and integrate solutions perfectly into your existing systems. They also welcome outstanding OEMs to discuss technology with them for mutual development.
Comprehensive Product Service
At TKT, our commitment to customer satisfaction goes far beyond product delivery. We offer a full suite of tailored services to support our clients at every stage of their journey:
– Consulting and customization: Our team of experts works closely with our customers to understand their specific requirements and tailor solutions to their goals and objectives.
– Installation and Integration: From initial setup to system integration, our experienced technicians ensure that the installation process runs smoothly, minimizing downtime and increasing efficiency.
– Training and Support: We offer comprehensive training programs to equip users with the knowledge and skills needed to optimize system performance. In addition, our dedicated support team is on call 24/7 to handle any inquiries or problems.
